Medical Oxygen Plant Solution
Description
Technical Parameters
Medical-Grade Oxygen Purity
The system is engineered to produce high-purity oxygen suitable for medical applications, meeting the oxygen requirements for hospital pipelines, ICUs, operating rooms, and emergency wards.
Reliable Continuous Oxygen Supply
Designed for 24/7 automatic operation, the plant ensures a stable oxygen source for hospitals, especially in situations where external oxygen supply chains may be unreliable.
Cost-Efficient Oxygen Production
By generating oxygen on-site, hospitals can significantly reduce long-term expenses associated with oxygen cylinder refilling, delivery logistics, and storage management.
Compact and Scalable System Design
Medical oxygen plants are available in modular configurations, allowing healthcare facilities to expand oxygen production capacity as patient demand increases.
 NTK93 Series PSA Oxygen Plant Model Selection |
||||||
| No. | Models | Capacity (Nm3/hr) | Purity | Power consumption of 1Nm3 oxygen produced (kw/h) | Number of bottles filled in 12 hours (pcs) | Operator needed |
| 1 | NTK-5P | 5 | 93%+-3% | 3.54 | 10 | 2 |
| 2 | NTK-10P | 10 | 93%+-3% | 2.52 | 20 | 2 |
| 3 | NTK-15P | 15 | 93%+-3% | 2.31 | 30 | 2 |
| 4 | NTK-20P | 20 | 93%+-3% | 2.13 | 40 | 2 |
| 5 | NTK-25P | 25 | 93%+-3% | 2.01 | 50 | 2 |
| 6 | NTK-30P | 30 | 93%+-3% | 2.09 | 60 | 2 |
| 7 | NTK-40P | 40 | 93%+-3% | 1.81 | 80 | 2 |
| 8 | NTK-50P | 50 | 93%+-3% | 1.94 | 100 | 2 |
| 9 | NTK-60P | 60 | 93%+-3% | 1.62 | 120 | 2 |
| 10 | NTK-80P | 80 | 93%+-3% | 1.92 | 160 | 2 |
| 11 | NTK-100P | 100 | 93%+-3% | 1.83 | 200 | 2 |
| Design basis: Altitude：≤500m;RH：≤80%;Temperature：0℃-38℃;Filling pressure: 150Bar 40L Type Standard Cylinder | ||||||
Working Principle
Air Compression and Intake
Ambient air is drawn into the system and compressed by an air compressor, providing the necessary pressure for the oxygen generation process.
Air Filtration and Drying
The compressed air passes through multiple filters and air dryers that remove dust, oil, and moisture, ensuring clean and dry air before entering the oxygen generator.
PSA Oxygen Separation Process
Inside the PSA oxygen generator, specialized molecular sieve materials selectively absorb nitrogen from the compressed air, allowing oxygen to pass through and be collected as the output gas.
Oxygen Storage and Hospital Distribution
he produced oxygen is stored in a buffer tank and then delivered through a medical gas pipeline system to hospital departments such as ICU units, operating rooms, and patient wards.
why choose NEWTEK ?
●Complete Medical Oxygen Supply Solutions
NEWTEK provides fully integrated medical oxygen systems, including compressors, PSA oxygen generators, oxygen tanks, and pipeline solutions tailored for healthcare facilities.
●Ensuring Oxygen Availability for Critical Care
The system helps hospitals maintain a reliable and independent oxygen source, reducing dependence on external suppliers and preventing shortages during emergencies.
●Customized Solutions for Different Hospitals
NEWTEK designs oxygen plants according to hospital size, oxygen demand, and installation environment, ensuring efficient and practical deployment.
●Stable Performance and Long-Term Reliability
Using high-quality components and intelligent control systems, NEWTEK medical oxygen plants offer stable operation, low maintenance requirements, and long service life.
FAQ
1. What purity level does a medical oxygen plant produce?
Medical oxygen plants typically produce oxygen with purity levels between 90% and 95%, which is suitable for most medical oxygen supply systems.
2. Is a medical oxygen generator safe for hospital use?
Yes. Medical oxygen plants are designed with advanced monitoring systems, alarms, and safety controls to ensure safe and reliable operation in healthcare environments.
3. Can a medical oxygen plant replace oxygen cylinders?
In many hospitals, on-site oxygen generation can significantly reduce or even replace the need for oxygen cylinders, improving supply stability and reducing operational costs.
4. What size oxygen plant does a hospital need?
The required capacity depends on the number of hospital beds, oxygen consumption rate, and peak demand, and systems can be customized accordingly.
5. How long does it take to install a medical oxygen plant?
Installation time varies based on system size and site conditions but generally takes several days to a few weeks.
6. What maintenance is required for a medical oxygen plant?
Routine maintenance typically includes filter replacement, compressor servicing, and periodic system inspection, ensuring consistent performance and oxygen purity.
